Light source | LED660W (white light) |
Light source life | 30000-50000 hours |
Indicator | CRI≥70/CRI95 optional |
Focusing | high-precision glass lens, electronic linear high-definition
focusing |
Light output angle | 7°~42° linear high-speed zoom |
| |
Dynamic pattern | 1 rotating pattern plate has 7 optional pattern pieces |
Alternative patterns | 1 fixed gobo plate and 8 gobos, variable speed jitter/bidirectional
rotation effect |
Alternative patterns | 1 dynamic fire plate, or linear CTO correction film |
| 600W |
Fixed color | 1 fixed color plate with 7 color chips, linear color conversion and
half-color rainbow effect |
| 3-pin XLR waterproof plug input/output |
4 gratings realize fast and smooth cutting, and the cutting
direction and angle of each grating can be controlled
separately.And a single chip can achieve complete light closure,
and the entire cutting module has an aperture | |
| |
Channel mode | 16 channels |
| |
Communication design | DMX wired transmission, master-slave, self-propelled, gradual
change, RDM two-way control technology, remote function effect upgrade Display screen: LCD liquid crystal display, can be reversed
180 ° display, bilingual menu in Chinese and English |
| |
Input voltage | 110V-240V 50-60Hz |
Rated power | 750W |
Power interface | waterproof plug input/output |
Signal interface | Signal interface |
| |
Channel mode | 27/36 channels |
Communication design | DMX wired transmission, master-slave, self-propelled, gradual
change, RDM two-way control technology, remote function effect
upgrade |
Display screen | LCD liquid crystal display, can be reversed 180 ° display,
bilingual menu in Chinese and English |
| |
Horizontal/Vertical | Horizontal scanning angle 540°, vertical scanning angle 270° 16 bit
precision scanning |
Correction | automatic return correction and 16Bit precision fine-tuning
function, using digital waveform correction technology to ensure
accurate positioning of the X/Y axis, It will not run after
high-speed operation and reset. |
Prism | independent rotation of 4 prism effects, 16 macro functions? |
Dimming | 0%-100% linear dimming |
Stroboscopic | 1-25Hz fast strobe per second, with pulse strobe, synchronous and
asynchronous strobe effect |
| |
Sensor detection function | adopts photoelectric reset system, when accidental error occurs, it
can automatically retrieve and reset appearance |
Automatic energy saving | an intelligent tracking energy saving system that reduces the power
of the light source in time. |
Sleep function | When the lamp is disconnected from the signal, it will
automatically enter the dormant state, making the lamp more stable
and
safer. |
Heat dissipation design | adopts wind direction drainage and temperature intelligent
monitoring technology, automatically adjusts the heat dissipation system, and effectively controls the temperature of the lamp. |
Physical/installation characteristics | |
Appearance | high temperature resistant plastic + molded alloy material |
Working environment | -20℃-40℃ |
Protection grade | IP20 |
Net weight | 24Kg |
Lamp size | 420mm×310mm×730mm |
Packaging accessories | 1 manual, 1 safety rope; 2 light hookCompany Pr |
